MCWlaser 200W Laser Rust Removal Machine Handheld Pulse Laser Cleaning Machine Trolley Type
2.Lifetime Free Technical Support and Easy-to-Follow beginner courses.
3.$50-$300 Cash Back For Customer Feedback
4.More Discount for regular customers
The 200W laser cleaning machine has high optical pulse energy, stable output, and strong applicability of index parameters. The machine has a self-developed electronic control system, can avoid excessive ablation during cleaning of both ends and realize efficient and precise cleaning without substrate damage.
With a compact and portable output head, the machine can realize long-term, stable, flexible, and continuous operation.
It can pre-set multiple cleaning modes, has superior operability and practicability, and may realize favorable cleaning effects, especially to the rust, oil, paint, and oxide on the surfaces of various molds, metal parts, industrial equipment, and decks.
★ Easy and convenient operation.
★ Certified: FDA and CE
★ 2-Year Warranty and Lifetime Free Technical Support.
★ Door to door service with free delivery.
It is easy to move around and useful for cleaning large or multiple objects.
User-friendly interface. The controls are clearly labeled and easy to find.
Compact laser cleaning machines can be used to clean small, intricate parts and surfaces with precision.
Operating Environment | |
Model | MC-200L-WF |
Supply voltage | 100-240 volts AC; 50/60Hz AC |
Power consumption | ≤ 1000W |
Working environment temperature | 5℃~40℃ |
Working environment humidity | ≤80% |
Optical Parameters | |
Average laser power | ≥100W |
Power instability | ≤ 5% |
Laser Working Mode | Pulse |
Pulse width | 10-500ns |
Maximum monopulse energy | 1.5mJ |
Power regulation range(%) | 0- 100( Gradient Adjustable) |
Repeat frequency(kHz) | 133-150 (Gradient Adjustable) |
Fiber length | 3m |
Cooling mode | Air Cooling |
Cleaning Head Parameters | |
Scan range (length * width) | 0- 120mm ,continuously adjustable; |
Biaxial: supporting 8 scanning modes; | |
Field mirror focal length(mm) | 160mm(Optional 210mm/254mm/330mm/420mm) |
Mechanical Parameters | |
Machine size(LxWxH) | 488×354×372mm |
Weight of whole machine | 25Kg |
Cleaning head weight | 1.1±0.15kg |
Operation mode | Handheld/automated |
Cleaning efficiency (m2/h) | Rust: 6-8m 2/h, Light oil: 10-13m 2/h, Aluminum oxide: 6-9m 2/h, Paint: 2-4m 2/h (Paint thickness affects cleaning results) |
Laser Cleaning Mahcine Efficiency
The Portable Handheld Pulse Laser Cleaning Machine is a tool designed for removing contaminants, rust, paint, and other unwanted materials from surfaces using laser technology. Offers higher precision and control over the depth of material removal. It is effective for selective cleaning applications where specific contaminants need to be removed without affecting the underlying substrate.
Its applications can be found in various industries. Some common applications include:
Metal Surface Cleaning(including Rust and Paint Removal),Industrial Maintenance,Historical Artifact Restoration,Automotive Industry,Aerospace Industry,Electronics Manufacturing, Construction Industry, Nuclear Industry, Shipbuilding and Maritime Applications,Oil and Gas Industry.
